Real or Repro...It’s a Mystery!©

Author’s note -- I hope that you enjoy learning from this resource! To help me to continue to provide valuable free content, please consider showing your appreciation by leaving a donation HERE. Thank you and Happy Trails!

It’s a mystery. I bought a sword at an antique store; it didn’t have any maker’s marks, any inspector’s markings or even the year stamped on the blade or grip. It did have a patina on the blade and on parts of the hilt that made me think it might be old, there were hammer-marks on the tang, and the blade still had a sharp edge...but patinas can be faked, and anything can be sharpened.

Just what type of sword is it and did I get a real antique, or a modern fake? I had my suspicions, but no proof and that is why it was a mystery!

The mystery sword has a one piece hilt and cross guard that are of cast brass. The brass hilt has a fish scaled grip, a nippled pommel, and a 4 inch (10 cm) cross guard. The grips have been molded in a scalloped fish scale design with no visible rivets. The pommel is decorated on each side with a heavily embossed American eagle, with shield, holding arrows in his left talon and an olive branch in his right talon. The straight cross quillons terminate in disk shaped finials.

The tang is an extension of the blade that runs mostly unseen through the grip and allows for the blade, grip, and guard to be bound together. The tang on the mystery sword is slightly irregular and has several hammer marks on, indicating that it was hand made.

The end of the tang on the mystery sword is threaded to accept a heavily embellished nut, called a “Capstan” or “Kapstan”, which holds the blade to the grip.

The sword has an overall length of 25 ¼ inches (64 cm) and has a double-edged blade with single and double fullers on both sides. The blade is elliptical in cross section, and tapers slightly for the first four inches before widening again, then coming to a spear point.

The blade washer on the mystery sword is missing, which is often the case with old swords. Blade washers are designed to decrease shock, reduce looseness between the grip and the blade, lessen noise, and prevent water from entering the scabbard. Blade washers were predominantly made of leather, however on imported European swords, cloth, particularly red wool was common.

The mystery sword looks like a U.S. Model 1832 Foot Artillery sword, which was a “Roman gladius” style short sword, that was based on the French foot artillery sword of 1816.

U.S. Model 1832 Foot Artillery sword was the first sword ordered by the U.S. army from the Ames Manufacturing Company of Springfield¹, Massachusetts, and started production in 1832, which is why it is the Mosel 1832. In later years, blades were imported and supplied with grips and scabbards by W.H. Horstmann & Sons of Philadelphia, Pennsylvania.

The sword was intended as a personal weapon for use by the regular and foot artillery regiments of the U.S. Army and were standard for both because both artillery and infantry regiments were trained and equipped as infantry prior to 1861. It was issued to sergeants, drummers and fifers of infantry regiments from 1832 until 1840 and remained in service until 1872, with foot artillerymen.

Many modern historians feel that this sword was impractical for actual combat, since the infantryman’s bayonet or cavalryman’s saber has the advantage in reach over it². Reportedly however, it was put to other uses, such as clearing brush or creating trails, uses which are supported by the French nickname for their version of this sword, the “coupe choux” or “cabbage cutter”.

It would appear that the mystery sword is a U.S. Model 1832 Foot Artillery, but who made it and is it a real antique or just a reproduction.

The mystery sword’s grip was cast in one piece since the feather scales show an intact pattern along both sides of the grip. A grip that was cast in two pieces and then brazed together would not have a pattern along the edges, just a smooth seam line.

The mystery sword doesn’t have rivets holding the grip to the blade, so we know that it was not manufactured by Ames Manufacturing.

William H. Horstmann & Sons of Philadelphia, Pennsylvania also manufactured U.S. Model 1832 Foot Artillery swords. They could make every part of the sword and its trappings on site, except for the blades. Blades were imported from Solingen, Germany and then fitted onto the grips, at their manufacturing/show room located on the corner of North Fifth and Cherry Streets, in Philadelphia.

But since there are no markings on the blade or the grip, can we be certain that the mystery blade was manufactured by W.H. Horstmann & Sons and that it is, in fact, a genuine antique?

The missing blade washer, the patina and the hammer marks indicate that it is probably a genuine antique and since Liveauctioneers sold a Model 1832 sword which they believed to be manufactured by W.H. Horstmann & Sons, and which had a capstan identical to the mystery sword’s on September 8th, 2022, it is likely that the mystery sword is, in fact, a U.S. Model 1832 Foot Artillery sword manufactured by W.H. Horstmann & Sons of Philadelphia. Mystery solved!

I hope that you enjoy learning from this resource! To help me to continue to provide valuable free content, please consider showing your appreciation by leaving a donation HERE. Thank you and Happy Trails!

I hope that you continue to enjoy The Woodsman’s Journal Online and look for me on YouTube at BandanaMan Productions for other related videos, HERE. Don’t forget to follow me on both The Woodsman’s Journal Online, HERE, and subscribe to BandanaMan Productions on YouTube. If you have questions, as always, feel free to leave a comment on either site. I announce new articles on Facebook at Eric Reynolds, on Instagram at bandanamanaproductions, and on VK at Eric Reynolds, so watch for me.

That is all for now, and as always, until next time, Happy Trails!

Sources

American Swords LLC; “Basic Sword Anatomy”, [©American Swords, LLC, 2014-2024], https://www.americanswords.com/the-sword---info.html, January 11, 2025

U.S. Army Center of Military History; “1866 Willard Civil War Uniform Photos”, [Quartermaster Museum, 2220 Adams Avenue, Fort Gregg-Adams, VA], https://qmmuseum.army.mil/research/primary-sources/civil-war/Willard-Uniform-Photos/index.html, accessed January 11, 2025

Workshopoftheworld; “William H. Horstmann & Sons, Manufacturers of Dress Trimmings and Military Goods”, [© 2007 workshopoftheworld.com], https://www.workshopoftheworld.com/center_city/horstmann.html, accessed January 11, 2025

Sunday, January 5, 2025

Don’t Break The Ice! ... How Not To©

Remember that classic old game, “Don’t Break The Ice?”, it was a lot of fun! But breaking through the ice in real life isn’t, in fact it is downright deadly!

How do you know if the ice isn’t safe? Ice is tricky and just because a lake or river is frozen, it doesn’t mean that it is safe.

According to the U.S. Army Cold Regions Research and Engineering Laboratory in New Hampshire, you can’t tell the strength of ice just by looking at it, the daily temperature, the thickness, or whether it is covered by snow or not. Ice strength of ice is based upon a combination of the size of the water body, the water chemistry, the distribution of the of the ice, and local climatic factors, plus the depth of water under the ice. Below are suggestions that these researchers have on what to look for to stay safe.

At the ice’s edge, look for areas of open water, signs of recent changes in water levels, such as the ice sloping down from the bank as the water level dropped, or wet areas because the water has risen and flooded ice that couldn’t float, because it was frozen to the bottom or the banks. If the ice is covered in snow, look for wet areas in the snow.

Find an easy approach to the ice, free of cracks or piled, broken ice. Whether you are walking or taking a vehicle out on the ice, first check it out on foot. Using an ice chisel, strongly probe ahead of yourself.

Near the shore, listen for hollow sounds while probing. Ice sloping down from the bank may have air space underneath. This is not safe; ice must be floating on the water to support weight.

If the ice chisel goes through, cautiously turn around and retrace your steps back to shore and try again another day or somewhere else.

Others in a group should follow in the leader's steps but stay at least 10 feet (3 meters) apart.

Drill or chop a hole through the ice and check the thickness every 150 feet (45 meters) or so along the intended path. Ice seldom freezes or thaws at a uniform rate, and it can be a foot thick (30 cm) in one spot while, 10 feet away, only an inch thick (1 cm). If the ice thickness is variable, check more frequently.

Measure the thickness and see if the ice in each hole is clear white, or grey ice.

The strongest and safest ice is clear ice (also sometimes called blue or black ice), and typically forms at the start of the season on top of calm water. This ice is clear but can appear blue or black, when looking down into the water.

White ice occurs when snow melts on top of a sheet of ice and then refreezes. This type of ice is only about half as strong as new, clear ice because it is full of air bubbles and is made up of smaller crystals.

Gray or “rotten” ice may appear transparent or splotchy grey and is a loose term for ice that is melting or being honeycombed with liquid water or air, it is generally found after spring or summer thaws.

Frozen lake or stream water will be stronger than ice formed by melting snow, refrozen ice, or ice made by water bubbling up through cracks in the ice and freezing on the surface.

Remember, several inches of new ice may be strong enough to support you, while a foot or more of old rotten ice may not be.

Measure the thickness of snow cover on the ice, different thickness of snow may mean different thicknesses of ice, because snow is a good insulator, slowing down the formation of ice. Also, the weight of snow can decrease the carrying capacity of the ice.

If the snow cover is heavy enough, the ice sheet will sag below the water level. Then water will flood through cracks in the ice, saturating the lowest layers of the snow and making slush. When the saturated snow/slush freezes, it will add a layer of white ice to the original layer of black ice. However, until this slush freezes, stay off the ice sheet.

River ice is dangerous and is about 15 percent weaker than lake ice. On rivers, ice thickness and quality can change quickly due to bends, shallows, or tributaries. The problem with rivers is that there is always water moving underneath the ice and no matter whether the current is slow or rapid, water can be pushed up from deeper depths, where the water is warmer, to the surface. This creates thin spots, and once a person falls through, the current can carry you under the ice. Straight, smooth flowing stretches are safer than river bends. River mouths are dangerous because the incoming current undermines the ice and creates thin ice.

For both rivers and lakes, warmer water from springs can create areas of thin ice. The ice near shores can either be thinner, due to warm groundwater flowing in or the insulating effect of drifted snow, or thicker, because of the candle-dipping effect of changing water levels. Ice near the shore is weaker, because the buckling action of the lake or stream continually breaks and refreezes ice near the shore.

If the air temperature has been above freezing for at least 6 of the past 24 hours, use the 1.3 lower dashed line on the graph to the right, obtaining a larger minimum ice thickness to account for any possible weakening. If the air temperature stays above freezing for 24 hours or more, the ice starts losing strength, and the graph no longer represents safe conditions. Stay off the ice!

You are likely to encounter cracks in the ice. Cracks are either wet or dry. If they are dry, they do not penetrate the ice sheet and are not a concern. If they are wet, use the 2.0 upper dashed line on the graph to obtain the required minimum ice thickness. The same for if you plan to leave a load on the ice for extended periods, more than two hours.

If you cross wet cracks, your path should be as close to perpendicular to them as possible, instead of parallel to them.

And contrary to what you might expect, a rapid, large air temperature drop makes ice more brittle, and the ice may not be safe for 24 hours or more.

If you hear ice “booming” or cracking on cold days or still evenings, it doesn't necessarily mean that the ice is dangerous, only that it's changing shape as the temperature changes. On a lake larger than several acres such noises may be harmless responses to thermal expansion and contraction, however on a river this may mean the ice is about to break up or move.

A potential danger spot on lakes is an open portion surrounded by ice. Winds will force exposed water beneath the ice and rot it from below. the actions of birds and fish can weaken ice, for example, schools of carp can create thin spots in the ice, or even open water, by schooling in one location moving the water with their fins, in effect creating a current.

So, if you are out on the ice this winter, remember don’t break the ice!

That is all for now, and as always, until next time, Happy Trails!

Sources

City of Corning Fire Dept; “The Dangers of River Ice”, [Corning, NY], https://www.cityofcorning.com/vertical/sites/%7BBE0E976C-81B9-4F4C-8763-A90E76CF4D33%7D/uploads/The_Dangers_of_River_Ice_2016.pdf, accessed January 4, 2025

McQueeney, Kerry; “Caught on camera: The terrifying moment girl plunges through ice into lake after being egged on by friends... and lives to tell the tale”, Daily Mail, February 15, 2012, [Associated Newspapers Ltd], https://www.dailymail.co.uk/news/article-2101030/Pictures-girl-falling-ice-lake-egged-friends.html, accessed December 28, 2024

U.S. Army Cold Regions Research & Engineering Laboratory;

“Safety on Floating Ice Sheets”, [U.S. Army Corps of Engineers, Hanover, New Hampshire], https://rivergages.mvr.usace.army.mil/WaterControl/Districts/MVP/reports/ice/safety.html, accessed January 4, 2025

U.S. Department of the Army; “Engineering and Design: Ice Engineering, EM 1110-2-1612”, September 30, 2006, [U.S. Army Corps of Engineers, Washington, DC 20314-1000], https://www.publications.usace.army.mil/Portals/76/Publications/EngineerManuals/EM_1110-2-1612.pdf, accessed January 4, 2025

Sunday, December 29, 2024

George Silver, True Times and the Blink of an Eye! Part Two©

Author’s note -- since few people today use swords in combat or otherwise engage in hand to hand combat, most modern research involves the use of handguns, or the ability to brake a vehicle, however this fact does not change the conclusion reached in this article.

Also, I hope that you enjoy learning from this resource! To help me to continue to provide valuable free content, please consider showing your appreciation by leaving a donation HERE. Thank you and Happy Trails!

So, once you have reacted and decided to do something, just how long does it take to complete an action, what can be done in a second, and just how does it all apply to George Silver and his true times?

The time of the hand...

Actions that only involve the “time of the hand” are the fastest, since they only require using a small portion of the body. These are actions that only use movements of the wrist, hand and fingers to achieve the required action.

How fast is fast? Bill Lewinski, writing in The Police Marksman, wrote that if a pistol is already pointed at a target, it takes just 0.03 of a second to confirm a sight picture, before the trigger pull, if the wielder has his or her finger on the trigger. If your finger is off the trigger, it takes an additional 0.06 seconds to move your finger to the trigger. This is consistent with researcher J. Peters Blair, et al., who noted that it took 0.08 seconds to complete the actual physical motion of moving your finger from a resting position to a firing position.

The time of the hand and the body...

Actions that require moving the hand, the arm and the torso to complete take longer than those that only use the movements of the wrist and hand, which is why the outlaw on the right is in trouble.

Researchers studying the “21 Foot Rule”¹, found that an average trained person can draw, aim and fire a handgun in 1.80 seconds. Other sources suggest that private citizens should be able to draw from concealment in 2 seconds flat, while professionals should be able to draw in 1.5 seconds or better, and experts in just 1 second.

The time of the hand, body, and foot...

A step, the action of putting one leg in front of the other while walking or running, involving motions of the arm and hand, the body and one leg, is an example of “the time of the hand, body, and foot”. A step takes, depending on your pace, between 0.5 and 1.0 seconds, So, the motion of taking a step forward into attack stance from a neutral position or swinging a forward leg back to avoid an attack all add time and make any action requiring a leg to move, to take longer than “the time of the hand and the body” alone.

Even crumpling to the ground from a standing position, according to the Force Science Institute, takes on average 1.1 seconds!¹

The time of the hand, body, and feet...

Charging an opponent is an example “the time of the hand, body, and feet” and is the slowest of all movements. This “true time” is demonstrated by the “21 Foot Rule”², and according to the “21 Foot Rule”, a person can charge forward and cover 21 feet, or 6.4 meters, in just 1.5 seconds. This means a person can charge towards you at seven feet, or 2.1 meters, every 0.5 seconds.

Against an aware and prepared defender, charging is asking to get dead! This is because a prepared defender, who has his or her finger on the trigger, with a sight picture, can fire four times during the time it takes you to sprint 21 feet, or 6.4 meters!

But action always beats reaction, and against an unprepared defender a charging attacker normally wins. This is because the defender now must go through the entire reaction sequence of the perception, decision and response phases, which on average uses up 0.31 to 0.56 seconds.

So, now we know just how long it takes to complete various actions, what can be done in a second, and how it all applies to George Silver and his true times?

That is all for now, and as always, until next time, Happy Trails!

Sources

ARCCA; “Human Reaction Time in Emergency Situations”, October 1, 2021, https://arcca.com/blog/human-reaction-time-in-emergency-situations/, accessed December 18, 2024

Backyardbrains.com, “Experiment: How Fast Your Brain Reacts To Stimuli”, [© 2009-2017 Backyard Brains], https://backyardbrains.com/experiments/reactiontime#:~:text=Looking%20at%20your%20data%20you,seconds%20for%20a%20touch%20stimulus, accessed December 21, 2024

Blazepod; “What is a normal reaction time?”, November 26, 2024, https://www.blazepod.com/blogs/all/what-is-a-normal-reaction-time, accessed December 18, 2024

Irving, Phil; “Human Reaction Must be Taken Into Account”, The Age, May 18, 1954, page 10, https://books.google.com/books?id=1vZjAAAAIBAJ&pg=PA6&dq=%22reaction+time%22&article_id=6806,2382176&hl=en&sa=X&ved=2ahUKEwjXm7yP1buKAxVsFlkFHe8AIbg4ChDoAXoECAsQAg#v=onepage&q=%22reaction%20time%22&f=false, accessed December 22, 2024

J. Peter Blair, et al.; “Reasonableness and Reaction Time”, Police Quarterly, Vol. 14, No, 4, pages 323 to 343, https://alerrt.org/r/21, accessed December 21, 2024

Jones, Roy D., Col.; “Gun Fighting Police Doom Gangsters”, Popular Mechanics, September 1930, page 456, https://books.google.com/books?id=deIDAAAAMBAJ&pg=PA452&dq=break+down+of+the+time+it+takes+to+draw+aim+and+fire+a+pistol+seconds&hl=en&sa=X&ved=2ahUKEwiPl6atobmKAxUnElkFHaeQE-EQ6AF6BAgGEAI#v=onepage&q=break%20down%20of%20the%20time%20it%20takes%20to%20draw%20aim%20and%20fire%20a%20pistol%20seconds&f=false, accessed December 21, 2024

Lewinski, Bill, Ph.D.; Biomechanics of Lethal Encounters Officer Movements, The Police Marksman, November/December 2002, Vol. XXVII, No. 6, page 19 to 23, http://rochester.indymedia.org/sites/default/files/biomechanics.pdf, accessed December 22, 2024

Remsburg, Chuck; Force Science News, March 3, 2010, [© 2024 Force Science, Ltd.], https://www.forcescience.com/2010/03/excessive-shots-and-falling-assailants-a-fresh-look-at-ois-subtleties/, accessed December 22, 2024

Unknown; “Reaction Time”, St Petersburg Times May 28 1964, page 35F, https://books.google.com/books?id=lYAmAAAAIBAJ&pg=PA79&dq=%22reaction+time%22&article_id=5954,4670543&hl=en&sa=X&ved=2ahUKEwjXm7yP1buKAxVsFlkFHe8AIbg4ChDoAXoECAgQAg#v=onepage&q=%22reaction%20time%22&f=false, December 22, 2024
